公称通径 (mm) | 尺 寸(mm) | |
L | H | |
50 | 205 | 255 |
65 | 216 | 290 |
80 | 250 | 326 |
100 | 320 | 380 |
125 | 365 | 448 |
150 | 415 | 495 |
200 | 500 | 625 |
250 | 605 | 744 |
300 | 698 | 879 |
350 | 787 | 909 |
400 | 914 | 1130 |
450 | 978 | 1160 |
500 | 978 | 1198 |
600 | 1200 | 1600 |
700 | 1450 | 1750 |
800 | 1560 | 1900 |
900 | 1800 | 2100 |
1000 | 2000 | 2400 |
